Thin oil system hydraulic systems

Thin oil system hydraulic systems

1. Product Overview

Thin oil system hydraulic systems are hydraulic power and control systems  that use low-viscosity lubricants (such as ISO VG 32, 46, and 68) as the working  medium. They are widely used in industrial equipment, machine tools,  construction machinery, and other fields. The systems utilize precision pumps,  valves, and piping to achieve power transmission, lubrication, and cooling,  offering both high performance and a long lifespan.

2. Core Features

Efficient Lubrication: Low-viscosity oil reduces friction and loss, making it  suitable for high-speed or precision machinery.

High Thermal Stability: The oil exhibits excellent oxidation resistance,  extending system life.

Clean and Environmentally Friendly: Compared to high-viscosity oil, thinner  oil is easier to filter and leaves less impurities.

Energy Saving and Consumption Reduction: Low flow resistance reduces pumping  energy consumption.

Multifunctional Integration: Integrates lubrication, cooling, and pressure  control functions.

3. Main Components

Power unit: Gear pump plunger pump (pressure range 0.5-35 MPa).

Filtration system: high-precision filter element (β≥200, filtration accuracy  ≤10μm).

Cooling Unit: Air-cooled/water-cooled heat exchanger (temperature control  range 30-60°C).

Control Valve Assembly: Pressure valve, flow valve, directional valve  (optional electro-hydraulic proportional control).

Oil Tank and Piping: Made of stainless steel and carbon steel, with level and  contamination monitoring.
